Run-N-Seal® ECF™ Metal-Free Thread Sealant
RUN-N-SEAL ECF is a patented metal-free, environmentally safe, high-pressure sealant alternative for API-MODIFIED on thread seal connection designs such as 8-round, buttress & DINO VAM. The compound contains unique graphite and other non-metallic, inorganic, anti-wear additives blended into a high-quality calcium complex base grease. RUN-N-SEAL ECF contains a large volume of solids enhanced by a higher concentration of large-sized particles. The improved distribution of particle sizes and volume of solids provides an excellent seal in large and small diameter, non-shouldered or thread seal connection designs. The calcium sulfonate complex grease provides a high melting point, ensures brushability over a wide range of temperatures, and has excellent inherent water & corrosion resistance. It sticks to wet and oily steel, ensuring the compound will not wash off threads.
Benefits
- Contains additives for protection against rust, corrosion, and oxidation
- Prevents leakage (seals to 10,000 psi)
- High film strength to protect against wear, galling, and seizure
- H₂S Inhibited
Specifications
-
Base Materials
- Calcium Complex Soap / Vegetable & Synthetic
-
Friction /
Nut-Factor- 1.0 (Relative to API-MODIFIED)
-
Certifications
- Exceeds all of the performance criteria described in API spec. 5CT
- Tested in conformance with API RP 5A3
- Ospar Commission-HOCNF (Harmonized Offshore Chemical Notification Format) CLASSIFICATION: “Yellow” rating for Norway CLASSIFICATION: “E” for The United Kingdom & The Netherlands Denmark PR #: 2324106
